NEWAGE SS HYDRANT VALVE

Product Details:

Fire Class A, B, C
Material Stainless steel
Shape Right Angle (L Type)
Control Type Handwheel operated (Screw Down Type)
Weight 9 kg Kilograms (kg)
Coating Type Mirror Polished Stainless Steel
Connectivity Type Female Instantaneous Inlet
Share Your Product:

Get a Price/Quote

Request To Call Back Send Inquiry

NEWAGE SS HYDRANT VALVE Price And Quantity

Minimum Order Quantity 1 Number

Disc & Spindle Material Stainless Steel
Handwheel Material Aluminum alloy
Bonnet Material Stainless Steel (SS-304/316)
Weight Approximately 6 to 7 Kg
Surface Finish Polished / Natural Stainless Steel
Outlet Connection Female instantaneous to IS:903
Color Natural Stainless Steel/Silver
Body Material Stainless Steel (SS-304/316)
Test Pressure Hydrostatic Test at 2.4 MPa (24 bar)
Inlet Connection Flanged as per IS:5131 / 63 mm NB Flange

NEWAGE SS HYDRANT VALVE Product Specifications

Installation Type Flanged/Mountable
Mounting Type Flange Mounted or Wall Mounted
Features Corrosion Resistant, Rugged Design, Leak Proof, Low Maintenance
Coating Type Mirror Polished Stainless Steel
Product Type SS hydrant valve
Diameter 63 mm Millimeter (mm)
Connectivity Type Female Instantaneous Inlet
Working Temperature -10C to 80C
Warranty 1 year against manufacturing defect
Control Type Handwheel operated (Screw Down Type)
Weight 9 kg Kilograms (kg)
Coverage Area Depends on connected hose length and nozzle type
Operating Pressure 10 kg/cm2 maximum
Capacity Designed for high pressure and volume water discharge
Fire Class A, B, C
Technology Precision Machined Stainless Steel
Material Stainless steel
Fire Extinguisher Type Hydrant Valve (not extinguisher)
Max Flow Rate 900 LPM at 7 kg/cm2
Shape Right Angle (L Type)
Pressure Working Pressure up to 10 Bar
Application Fire Fighting Systems

Disc & Spindle Material Stainless Steel
Handwheel Material Aluminum alloy
Bonnet Material Stainless Steel (SS-304/316)
Weight Approximately 6 to 7 Kg
Surface Finish Polished / Natural Stainless Steel
Outlet Connection Female instantaneous to IS:903
Color Natural Stainless Steel/Silver
Body Material Stainless Steel (SS-304/316)
Test Pressure Hydrostatic Test at 2.4 MPa (24 bar)
Inlet Connection Flanged as per IS:5131 / 63 mm NB Flange

NEWAGE SS HYDRANT VALVE Trade Information

Supply Ability 400 Number Per Day
Delivery Time 5 Days
Sample Available Yes
Sample Policy Contact us for information regarding our sample policy
Packaging Details 4 PIECE IN CARTON
Main Domestic Market West India, Uttarakhand, Himachal Pradesh, Punjab, Karnataka, North India, All India, Chandigarh, Kerala, Sikkim, Haryana, Delhi, Telangana, Uttar Pradesh, Rajasthan, Tamil Nadu, Jammu and Kashmir, East India
Certifications ISI MARKED

Product Description

Discover the ineffable reliability of the NEWAGE SS HYDRANT VALVE, engineered from formidable stainless steel (SS-304/316) for world-class fire fighting performance. With a Max Flow Rate of 900 LPM at 7 kg/cm2, its rugged, corrosion-resistant design guarantees both durability and leak proof efficiency. Installation is seamless with a 63 mm NB Flanged connection, while the mirror polished finish provides a professional edge. Enjoy the best price-affordable quality and excellence you can trust. Add to Cart now for rust-free protection with a 1-year warranty!

Suitable for Multiple Fire Fighting Applications

The NEWAGE SS HYDRANT VALVE is meticulously designed for both general and specific use in fire fighting systems, making it suitable for commercial, industrial, and institutional environments. Its robust construction ensures dependable performance under all class A, B, and C fire scenarios. Key features include a right angle (L type) shape, high flow capacity, corrosion resistance, and low maintenance requirements, offering lasting protection across diverse installation settings.

Prime Export Standards and Reliable Delivery

NEWAGE SS HYDRANT VALVE is shipped from major Indian FOB ports, ensuring prompt delivery to global destinations. With main export markets in Asia, Middle East, Africa, and beyond, customers benefit from competitive rates and secure, robust packaging. The typical delivery time is optimized to keep client expenditure reasonable without compromising expediency. Our streamlined logistics ensure that your fire safety expenditure yields premium reliability every time.

FAQ's of NEWAGE SS HYDRANT VALVE:

Q: How does the NEWAGE SS HYDRANT VALVE enhance fire fighting system efficiency?

A: Its high-capacity design delivers up to 900 LPM at 7 kg/cm2, allowing for swift and effective fire suppression, making it invaluable for emergency responses in various settings.

Q: What makes the NEWAGE SS HYDRANT VALVE corrosion-resistant and long-lasting?

A: The valve and critical components are crafted from premium stainless steel (SS-304/316) and polished to a mirror finish, ensuring formidable resistance to rust and environmental wear.

Q: Where can the NEWAGE SS HYDRANT VALVE be installed?

A: It can be mounted on walls or flanged installations, making it versatile for use in commercial, industrial, residential, and institutional buildings requiring reliable fire protection.

Q: What is the process for handling installation and maintenance?

A: Installation is straightforward with standard flange mounting. Maintenance is simple, requiring routine checks for optimal operation. Its leak proof and low maintenance design minimizes long-term upkeep.

Q: What is included in the product warranty?

A: The product carries a 1-year warranty against manufacturing defects, providing added peace of mind and value for every purchase.
